RDT Rotary Drum Thickener For Municipal Sludge Treatment

Rotary Drum Thickener for Municipal Sludge Treatment in Factory, Corrosion Resistant, Good Performance - DHNS Series

How Rotary Drum Thickening Works:

Rotary drum thickening increases the sludge solids concentration (i.e. thickens the sludge) by agitating the solids in a slowly-rotating vessel with porous walls through which the water (or filtrate)drains.

A rotary drum thickener operates on the principle common to that of a gravity belt thickener. in that water drains from the sludge through a retaining porous medium. For a Rotary drum thickening, the porous medium is the cylindrical wall of a 0.5−1.5 m diameter drum which rotates at speeds between 5 and 20 RPM while the sludge continually passes through it.

The porous wall may be fabricated from a range of materials, including polymers, steel, and ceramics. A spray system is used to clean the drum and prevent the pores from blocking.

Rotary drum thickening can achieve solids concentrations up to 9% and corresponding solids recoveries of 90−99%, depending on the sludge source and the condition employed. Conditioning by polymer dosing is normally conducted in a mixing drum upstream of the Rotary drum thickening.

Peripheral Configuration:

Applications:

• For the various Industry Waste Slurry pre-thickening Treatment.

• For the solid and liquid separation of the industrial processing treatment of Paper &Pulp, Fiber, Chemical, Food, Plastic, Metallurgy, Mining, etc. Industries.

• For the raw material processing filtering-recovering of the brewing, flavoring, stuffing, starch factory, and the various food-processing factory.

• The filtering before tap-water intaking, the filtering-recovering of the rainwater.

  The solid and liquid separation of the fruit processing industry, and vegetable processing industry.

• The engineering drainage and large-size water treatment of municipal sewage, paper&pulp industry sewage, fiber-industry sewage, chemical-industry sewage, etc.

• The filtering-removing the dross pellet of the winery industry, and pickled industry.

Specifications:

Remarks:

Our company will reserve the modifying right of the above specifications.

Treating capacity and water content rate depend on the slurry feature.

Please call us for actual installation dimensions before ordering.

Q1: How to pay?

A: 100％T/T, Paypal, West Union, MoneyGram, Secure payment and Trade Assurance.

Q2: What's the delivery time?

A: 30-60 days.

Q3: What's the MOQ?

A: The MOQ is one set.

Q4: Do you have an inspection report for the material?

A: We can provide you with the relative certificates.
