Product Description:
The DAF-MB mobile containerized dissolved air flotation system delivers rapid-deployment wastewater treatment in a standard 20ft or 40ft shipping container. All components—dissolved air tank, flotation chamber, skimmer, chemical dosing, and control panel—are pre-installed and factory-tested inside the container module. Simply connect inlet, outlet, and power to begin treatment within 24 hours. With 2-50 m3/h capacity, this portable DAF unit is ideal for temporary projects, remote mining camps, emergency response, and pilot-scale operations across Latin America where infrastructure is limited.
Features:
- Product Name: Mobile Containerized Dissolved Air Flotation DAF System
- Model: DAF-MB
- Application: Rapid Deployment Industrial Wastewater Treatment
- Material: Stainless Steel 304 with Container Frame
- Treatment Capacity: 2-50 m3/h
- Configuration: 20ft/40ft Standard Container Module
- Deployment Time: Plug-and-Play within 24 Hours
- Automation: Fully Automatic PLC with Remote Monitoring
DAF / IDAF Technical Specifications:
| Model |
Capacity |
Power (kW) |
Dimension (m) |
Nozzle list (DN) |
DAF/
IDAF |
m³/h |
Recycle
pump |
Air
compressor |
Skimmer |
IDAF
Fast mixer |
IDAF
Slow mixer |
DAF
L₁/L₂ |
IDAF
L₁/L₂ |
W₁/W₂ |
H₁/H₂ |
Inlet
(a) |
Outlet
(b) |
Sludge
outlet (c) |
Vent
nozzle (d) |
| 003 |
~3 |
0.75 |
0.55 |
0.12 |
0.37 |
0.25 |
3.6/2.8 |
4.1/3.2 |
2.4/1.2 |
2.2/1.7 |
50 |
50 |
80 |
80 |
| 005 |
~5 |
1.1 |
0.55 |
0.12 |
0.37 |
0.25 |
3.8/3.0 |
4.4/3.6 |
2.4/1.2 |
2.2/1.7 |
80 |
80 |
80 |
80 |
| 010 |
~10 |
4 |
0.55 |
0.12 |
0.37 |
0.25 |
4.3/3.3 |
5.0/4.0 |
2.9/1.7 |
2.4/1.9 |
100 |
100 |
100 |
100 |
| 020 |
~20 |
4 |
0.75 |
0.12 |
0.37 |
0.25 |
5.7/4.8 |
6.2/5.2 |
3.2/2.2 |
2.4/1.9 |
150 |
100 |
100 |
100 |
| 030 |
~30 |
5.5 |
0.75 |
0.12 |
0.37 |
0.25 |
6.5/5.5 |
7.7/6.7 |
3.2/2.2 |
2.4/1.9 |
150 |
150 |
150 |
100 |
| 040 |
~40 |
5.5 |
0.75 |
0.12 |
0.75 |
0.37 |
6.5/5.5 |
7.7/6.7 |
3.6/2.7 |
2.4/1.9 |
200 |
200 |
150 |
100 |
| 050 |
~50 |
7.5 |
0.75 |
0.12 |
0.75 |
0.37 |
7.3/6.3 |
8.8/7.8 |
3.6/2.7 |
2.4/1.9 |
200 |
200 |
150 |
100 |
| 080 |
~80 |
11 |
1.5 |
0.12 |
1.5 |
0.37 |
8.9/7.6 |
10.6/9.2 |
4.4/3.4 |
2.7/2.3 |
250 |
200 |
150 |
100 |
| 100 |
~100 |
11 |
1.5 |
0.12 |
1.5 |
0.37 |
10.8/9.4 |
13.2/11.8 |
4.4/3.4 |
2.7/2.3 |
300 |
250 |
150 |
100 |
| 120 |
~120 |
11 |
2.2 |
0.12 |
1.5 |
0.37 |
11.7/10.4 |
14.2/12.8 |
4.4/3.4 |
2.7/2.3 |
300 |
250 |
150 |
100 |
| 150 |
~150 |
15 |
3 |
0.12 |
1.5 |
0.37 |
13.5/12.0 |
15.8/14.4 |
4.5/3.8 |
2.7/2.3 |
300 |
300 |
150 |
100 |
Process Flow Diagram:
Applications:
This mobile containerized DAF dissolved air flotation system is perfect for remote mining camp wastewater in the Andes (Chile, Peru, Bolivia), temporary construction site water treatment, emergency oil spill response in the Amazon and Orinoco basins, pilot-scale industrial wastewater testing, seasonal agro-industrial processing in rural Latin America, and rapid-deployment solutions for disaster relief operations. The plug-and-play container design enables immediate wastewater treatment capability without civil works.
Support and Services:
- Remote container commissioning support and on-site start-up for Latin America
- Real-time remote monitoring with PLC data access
- Scheduled maintenance and genuine spare parts delivery
- Operator training with English and Spanish documentation
- Container relocation and re-deployment support services
Packing and Shipping:
Product Packaging:
- Complete system pre-installed in standard ISO 20ft or 40ft container module
- All internal components secured and protected for ocean transport
- Includes operation manual, wiring diagram, and commissioning checklist
Shipping:
- Standard ISO container shipping via ocean freight to any Latin American port
- Container can be trucked directly from port to site without unpacking
- Full tracking and logistics support for door-to-door LATAM delivery
FAQ:
Q: What brand is this mobile DAF system?
A: DUBHE.
Q: What is the model?
A: DAF-MB (Mobile).
Q: How fast can it be deployed?
A: Plug-and-play within 24 hours after container placement, only requires power and pipe connection.
Q: Is container shipping included?
A: The DAF-MB is shipped as a complete ISO container module via standard ocean freight to all Latin American ports.
Q: What is the MOQ?
A: 1 set.
