Product Description:
The DAF-PO dissolved air flotation system is specifically engineered for palm oil mill effluent (POME) treatment, one of the most challenging agro-industrial wastewaters in Latin America. Through pressurized dissolved air micro-bubble technology, it efficiently separates residual palm oil, suspended solids, and colloidal organic matter from POME streams. The integrated oil skimming system recovers valuable residual palm oil while reducing pollutant load before anaerobic pond treatment. With 2-150 m3/h capacity, this DAF system is the sustainable choice for Latin American palm oil producers in Colombia, Ecuador, Honduras, and Guatemala.
Features:
- Product Name: Palm Oil Mill Effluent Dissolved Air Flotation DAF System
- Model: DAF-PO
- Application: Palm Oil Mill Effluent POME Treatment
- Material: Stainless Steel 304
- Treatment Capacity: 2-150 m3/h
- Oil Recovery: Integrated Oil Skimming
- Solid Content Handling: 30-100 g/L
- Automation: Semi-Automatic PLC Control
DAF / IDAF Technical Specifications:
| Model |
Capacity |
Power (kW) |
Dimension (m) |
Nozzle list (DN) |
DAF/
IDAF |
m³/h |
Recycle
pump |
Air
compressor |
Skimmer |
IDAF
Fast mixer |
IDAF
Slow mixer |
DAF
L₁/L₂ |
IDAF
L₁/L₂ |
W₁/W₂ |
H₁/H₂ |
Inlet
(a) |
Outlet
(b) |
Sludge
outlet (c) |
Vent
nozzle (d) |
| 003 |
~3 |
0.75 |
0.55 |
0.12 |
0.37 |
0.25 |
3.6/2.8 |
4.1/3.2 |
2.4/1.2 |
2.2/1.7 |
50 |
50 |
80 |
80 |
| 005 |
~5 |
1.1 |
0.55 |
0.12 |
0.37 |
0.25 |
3.8/3.0 |
4.4/3.6 |
2.4/1.2 |
2.2/1.7 |
80 |
80 |
80 |
80 |
| 010 |
~10 |
4 |
0.55 |
0.12 |
0.37 |
0.25 |
4.3/3.3 |
5.0/4.0 |
2.9/1.7 |
2.4/1.9 |
100 |
100 |
100 |
100 |
| 020 |
~20 |
4 |
0.75 |
0.12 |
0.37 |
0.25 |
5.7/4.8 |
6.2/5.2 |
3.2/2.2 |
2.4/1.9 |
150 |
100 |
100 |
100 |
| 030 |
~30 |
5.5 |
0.75 |
0.12 |
0.37 |
0.25 |
6.5/5.5 |
7.7/6.7 |
3.2/2.2 |
2.4/1.9 |
150 |
150 |
150 |
100 |
| 040 |
~40 |
5.5 |
0.75 |
0.12 |
0.75 |
0.37 |
6.5/5.5 |
7.7/6.7 |
3.6/2.7 |
2.4/1.9 |
200 |
200 |
150 |
100 |
| 050 |
~50 |
7.5 |
0.75 |
0.12 |
0.75 |
0.37 |
7.3/6.3 |
8.8/7.8 |
3.6/2.7 |
2.4/1.9 |
200 |
200 |
150 |
100 |
| 080 |
~80 |
11 |
1.5 |
0.12 |
1.5 |
0.37 |
8.9/7.6 |
10.6/9.2 |
4.4/3.4 |
2.7/2.3 |
250 |
200 |
150 |
100 |
| 100 |
~100 |
11 |
1.5 |
0.12 |
1.5 |
0.37 |
10.8/9.4 |
13.2/11.8 |
4.4/3.4 |
2.7/2.3 |
300 |
250 |
150 |
100 |
| 120 |
~120 |
11 |
2.2 |
0.12 |
1.5 |
0.37 |
11.7/10.4 |
14.2/12.8 |
4.4/3.4 |
2.7/2.3 |
300 |
250 |
150 |
100 |
| 150 |
~150 |
15 |
3 |
0.12 |
1.5 |
0.37 |
13.5/12.0 |
15.8/14.4 |
4.5/3.8 |
2.7/2.3 |
300 |
300 |
150 |
100 |
Process Flow Diagram:
Applications:
This DAF dissolved air flotation system is engineered for crude palm oil (CPO) mill sterilization condensate, sludge separator effluent, clarification wastewater, kernel crushing plant wash water, palm oil refinery acid water, and POME polishing before discharge. Trusted by palm oil producers across Latin America including plantations in Meta and Santander (Colombia), Esmeraldas (Ecuador), Cortes (Honduras), and Izabal (Guatemala) for sustainable POME management and RSPO environmental compliance.
Support and Services:
- Remote installation guidance and on-site commissioning for Latin America
- Troubleshooting and diagnosis of system operational issues
- Regular maintenance program and spare parts supply
- Operator training with bilingual documentation (English and Spanish)
- Equipment upgrades and performance optimization services
Packing and Shipping:
Product Packaging:
- Export-grade wooden case packaging with moisture-proof film wrapping
- Reinforced steel frame structure for long-distance ocean freight to Latin America
- Complete with installation manual, operation guide, and certification documents
Shipping:
- Sea freight to major Latin American ports: Santos, Buenaventura, Guayaquil, Puerto Cortes
- Shipping cost calculated based on destination port and order volume
- Tracking number provided upon shipment dispatch
FAQ:
Q: What brand?
A: DUBHE.
Q: Model?
A: DAF-PO (Palm Oil).
Q: Can it recover residual oil from POME?
A: Yes, integrated oil skimming recovers valuable residual palm oil while reducing pollutant load.
Q: Do you deliver to Colombia and Ecuador?
A: Yes, regular shipments to major Latin American palm oil producing regions.
Q: MOQ?
A: 1 set.
