Product Description:
The DAF-AQ dissolved air flotation system is specifically designed for aquaculture wastewater treatment and water recirculation in fish and shrimp farming operations. Utilizing advanced micro-bubble dissolved air technology, it efficiently removes suspended solids, uneaten feed particles, fish feces, algae, and colloidal organic matter from recirculating aquaculture systems (RAS) and pond discharge water. With 2-150 m3/h capacity and TSS removal above 90%, this DAF system enables sustainable water reuse and environmental compliance for Latin American aquaculture producers in Chile (salmon), Ecuador (shrimp), Brazil (tilapia), and Peru (trout).
Features:
- Product Name: Aquaculture Dissolved Air Flotation DAF System
- Model: DAF-AQ
- Application: Aquaculture Fish and Shrimp Farming Wastewater
- Material: Stainless Steel 304
- Treatment Capacity: 2-150 m3/h
- TSS Removal Rate: Above 90%
- Recirculation Ready: Yes
- Automation: Semi-Automatic PLC Control
DAF / IDAF Technical Specifications:
| Model |
Capacity |
Power (kW) |
Dimension (m) |
Nozzle list (DN) |
DAF/
IDAF |
m³/h |
Recycle
pump |
Air
compressor |
Skimmer |
IDAF
Fast mixer |
IDAF
Slow mixer |
DAF
L₁/L₂ |
IDAF
L₁/L₂ |
W₁/W₂ |
H₁/H₂ |
Inlet
(a) |
Outlet
(b) |
Sludge
outlet (c) |
Vent
nozzle (d) |
| 003 |
~3 |
0.75 |
0.55 |
0.12 |
0.37 |
0.25 |
3.6/2.8 |
4.1/3.2 |
2.4/1.2 |
2.2/1.7 |
50 |
50 |
80 |
80 |
| 005 |
~5 |
1.1 |
0.55 |
0.12 |
0.37 |
0.25 |
3.8/3.0 |
4.4/3.6 |
2.4/1.2 |
2.2/1.7 |
80 |
80 |
80 |
80 |
| 010 |
~10 |
4 |
0.55 |
0.12 |
0.37 |
0.25 |
4.3/3.3 |
5.0/4.0 |
2.9/1.7 |
2.4/1.9 |
100 |
100 |
100 |
100 |
| 020 |
~20 |
4 |
0.75 |
0.12 |
0.37 |
0.25 |
5.7/4.8 |
6.2/5.2 |
3.2/2.2 |
2.4/1.9 |
150 |
100 |
100 |
100 |
| 030 |
~30 |
5.5 |
0.75 |
0.12 |
0.37 |
0.25 |
6.5/5.5 |
7.7/6.7 |
3.2/2.2 |
2.4/1.9 |
150 |
150 |
150 |
100 |
| 040 |
~40 |
5.5 |
0.75 |
0.12 |
0.75 |
0.37 |
6.5/5.5 |
7.7/6.7 |
3.6/2.7 |
2.4/1.9 |
200 |
200 |
150 |
100 |
| 050 |
~50 |
7.5 |
0.75 |
0.12 |
0.75 |
0.37 |
7.3/6.3 |
8.8/7.8 |
3.6/2.7 |
2.4/1.9 |
200 |
200 |
150 |
100 |
| 080 |
~80 |
11 |
1.5 |
0.12 |
1.5 |
0.37 |
8.9/7.6 |
10.6/9.2 |
4.4/3.4 |
2.7/2.3 |
250 |
200 |
150 |
100 |
| 100 |
~100 |
11 |
1.5 |
0.12 |
1.5 |
0.37 |
10.8/9.4 |
13.2/11.8 |
4.4/3.4 |
2.7/2.3 |
300 |
250 |
150 |
100 |
| 120 |
~120 |
11 |
2.2 |
0.12 |
1.5 |
0.37 |
11.7/10.4 |
14.2/12.8 |
4.4/3.4 |
2.7/2.3 |
300 |
250 |
150 |
100 |
| 150 |
~150 |
15 |
3 |
0.12 |
1.5 |
0.37 |
13.5/12.0 |
15.8/14.4 |
4.5/3.8 |
2.7/2.3 |
300 |
300 |
150 |
100 |
Process Flow Diagram:
Applications:
This DAF dissolved air flotation system is engineered for salmon and trout raceway effluent treatment, shrimp pond discharge water clarification, tilapia RAS backwash water recovery, fish hatchery and nursery wastewater, aquafeed mill process water, and ornamental fish farm discharge. Serving major aquaculture operations across Latin America including Chilean salmon farms in Puerto Montt, Ecuadorian shrimp ponds in Guayaquil, Brazilian tilapia farms in Parana, and Peruvian trout operations in Puno for sustainable water management.
Support and Services:
- Remote installation guidance and on-site commissioning for Latin America
- Troubleshooting and diagnosis of system operational issues
- Regular maintenance program and spare parts supply
- Operator training with bilingual documentation (English and Spanish)
- Equipment upgrades and performance optimization services
Packing and Shipping:
Product Packaging:
- Export-grade wooden case packaging with moisture-proof film wrapping
- Reinforced steel frame structure for long-distance ocean freight to Latin America
- Complete with installation manual, operation guide, and certification documents
Shipping:
- Sea freight to major Latin American ports: Santos, Buenaventura, Guayaquil, Puerto Cortes
- Shipping cost calculated based on destination port and order volume
- Tracking number provided upon shipment dispatch
FAQ:
Q: What brand is this DAF?
A: DUBHE.
Q: What is the model?
A: DAF-AQ (Aquaculture).
Q: Is it suitable for RAS recirculation?
A: Yes, TSS removal above 90% makes it ideal for recirculating aquaculture systems.
Q: Do you ship to Chile and Ecuador?
A: Yes, we regularly deliver to all major Latin American aquaculture regions.
Q: MOQ?
A: 1 set.
