Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating

Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating

belt thickener wastewater treatment

gravity belt thickening

belt thickener

Place of Origin:

CHINA

Brand Name:

DUBHE

Certification:

ISO

Model Number:

GTB3

Contact Us

Request A Quote
Product Details
Features:
Continuous Auto Running;
Product Name:
Three Filter Belt Gravity Belt
Belt Width (mm):
750~2500
Treating Capacity (m3 /hr):
9.9~81.0
Water Content Rate (%):
65~84
Power Consumption (HP):
1.25~4
Application:
Dewatering Municipal And Industrial Sludge
Material:
Stainless Steel
Payment & Shipping Terms
Minimum Order Quantity
1Set
Product Description

Three Filter Belt Type Gravity Belt Thickening/Dehydrating Belt Filter Press-DTB3 Series

Industrial Belt Filter Press Solid Liquid Separation Processes-Standard Type-Suitable for Low/Middle Consistency

Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 0Description

The belt filter press (sometimes called a belt press filter, or belt filter) is an industrial machine used for solid-liquid separation processes.

A belt filter press is a type of industrial filtration equipment used to separate liquids and solids from a slurry mixture. The press consists of a series of belts that are arranged in a loop and used to filter the slurry as it passes through the press.

Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 0Application

1. The sludge dewatering of the various industrial wastewater treatment plants.

2. The sludge dewatering of the butchery, livestock, etc.

3. The sludge dewatering of the city sewer, excretion, water purifying, etc. Sewage treatment plants.

4. Solid and liquid separate under processing for the food & beverage, chemical industry, mine, etc.

Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 0Features

Integrated sludge dewatering system, continuous auto running;

Belt Thickener effectively improves the sludge solid content and flocculation

Flocculation system with patent reduces polymer consumption;

Good corrosion resistance;

The main structure is made of stainless steel;

Pneumatic tensioning device;

7-segment to 9-segment press rollers.

Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 3

















Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 0Benefits:

Continuous auto running;

Low power consumption, the longevity of service;

Easy to manage, easy to maintain;

Low noise, low consumption of PAM dosage ;

Economical, reliable, and wide application.

Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 0Belt Position Correcting System

This system can automatically keep detecting and rectifying the deviation of belt cloth, so as to guarantee the normal operation of our machine and also extend the lifespan of the belt.

■Press Roller
The press roller of our sludge belt filter press is made from SUS304 stainless steel. Additionally, it has gone through the TIG reinforced welding process and delicate finishing process, thus featuring a compact structure and ultra-high strength.

■Air Pressure Control Device
Tensioned by an air cylinder, the filter cloth can run smoothly and safely without any leakage.

Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 0How Our Belt Filter Press Works

- After flocculation and compression periods, the slurry is delivered to a porous belt for thickening and gravity dewatering.

- A large amount of free water is separated by gravity, and then the slurry solids are formed.

- After that, the slurry is sandwiched between two tensioned belts to pass through the wedge-shaped pre-compression zone, low-pressure zone, and high-pressure zone.

- It is extruded step by step to maximize the separation of sludge and water.

- At last, the filter cake is formed and discharged.

Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 7

Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 0Technical Data & External Dimensions of Belt Filter Press

Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 9

   Remark:
   1. Our company will reserve the modifying right of the above specifications.
   2. Treating capacity and the water content rate depend on the slurry feature

   3. Please ask for the actual installation dimension before ordering.

Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 0Allocation Schema for Peripheral Equipment



Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 11

Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 0The Reference Treating Data Sheet of The Major Waste Slurry

Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 13

Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 0Welcome to DUBHE

 Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 15 Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 16 Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 17

Sludge Gravity Belt Thickener Wastewater Treatment Dehydrating 18

Q1: How to pay?

A: 100%T/T, Paypal, West Union, MoneyGram, Secure payment and Trade Assurance.

Q2: What's the delivery time?

A: 30-60 days.

Q3: What's the MOQ?

A: 1 set.

Q4: Do you have an inspection report for the material?

A: We can provide relative certificates for our products.
